The wings rotate on the spar for pitch and roll, via bevel gears driven by 2 servos. There are no cams, slots, rod links or clevises typically used for wing control on these type gliders.
The fuselage and bevel gears are 3D printed, the servos are hobby RC servos, and the wings are conventional balsa covered foam.
